BARSTOCK OR FORGING

ASTM A 351 – CF8M (DIN 1.4408) or A182 – F316
ASTM A 351 – CF3 (DIN 1.4301) or A182 – F304
ASTM A 216 – WCB (DIN 1.0619) or A105
[dt_gap height=”10″ /]

FEATURES:

• PIPE THREAD IN ACCORDANCE WITH:

– ANSI B2.1(BASIC STD FOR STEEL PIPE THREADS)
– ANSI B1.20 (NPTF)
– BS21:1973
– DIN259/2999
– ISO228

• FULL PORT
• BLOW-OUT PROOF STEM
• PACKING: GFT , PEEK, Optional: KEL-F, POLYAMAN
• WORKING PRESSURE: 6000 PSI
• TEMPERTURE RATING:

• GFT 450 Deg ° F (232 Deg ° C)
• PEEK 700 Deg ° F (371 Deg ° C)

– BARSTOCK or FORGING BODY
– SEAT: DELRIN or PEEK

• MATERIALS: 316 SST, CARBON STEEL, HATELLOY, MONEL,

– STADARDS: BS 5750, ISO9001-2000, MSS SP-99

• TESTING

– EACH VALVE IS TESTED WITH N2 AT 1000 PSI FOR SEAT & SEAL LEAKAGE
– HYDRO TEST; PERFOMED WITH PURE WATER AT 1-1/2 TIMES OF THE WORKING PRESSURE
– OTHER TEST LIKE H2, SEISMIC ARE AVAILABLE UPON REQUEST
